85330ES2219PN
85330ES2219PN, Square Flange Receptacle, with 260? Stainless Steel Plating, with 360? teeth, Shell Size 22 with 19#16 Pin Contact, N Orientation.
[table “” not found /]
Technical Information
| Manufacturer: | Eaton Souriau |
| Shell Style: | Square Flange Receptacle |
| Shell Material: | Stainless Steel |
| Shell Plating: | Passivated |
| Coupling Method: | Screw Coupling |
| Shell Size: | 22 |
| Contact Gender: | Pin |
| Contact Size: | 19#16 |
| Contact Gender: | Male |
| Mating Cycles: | 500 |
| Orientation: | N |
| Operating Temperature: | -65? to +200?C (-149? to +392?F) |
| Salt Spray: | 500 hrs |
| Insert Arrangement: | 22-19 |
| RoHS Compliant: | Yes |
| Series: | 853 Series |
| Specification: | QPL |
| Qualified Status: | Commercial |
| Cross Reference: | EN2997SE02219MN |
ESC10 Datasheet | Contact Layout
|
Technical Specifications
| Manufacturer | Eaton Souriau |
|---|---|
| Contact Gender | – |
| Insert Arrangement | – |
| Shell Material | Passivated Stainless Steel |
