8D013F04AN
Eaton Souriau 8D013F04AN 8D Series III Square Flange Receptacle, Shell Size 13 with Aluminium Alloy Nickel Plating, 4#16 Less Pins Contacts, N Orientation. Ideal for Aerospace, Armoured Vehicles, Energy, Helicopter, Industrial, Maritime, Military, Naval, Railway.
Technical Specifications
| Manufacturer | Eaton Souriau |
|---|---|
| Connector Style | Square Flange Receptacle |
| Contact Gender | Less Pin Contacts, Pin – Male |
| Contact Size | 4#16 |
| Contacts Supplied | No |
| Insert Keyway | N |
| Insert Arrangement | 13-04 |
| No of Contacts | 4 |
| Shell Material | Aluminium Alloy |
| Shell Plating | Nickel, Nickel (F) |
| Shell Size | 13, 13 (C) |
| Termination Method | Crimp |
| Mating Cycles | 500 |
| Shell Continuity | 1 mΩ |
| Shielding | 65 db at 10 GHz |
Environmental Specifications
| Operating Temperature | -65°C +200°C – -85°F +392°F |
|---|---|
| RoHS Compliant | Yes |
| Salt Spray | 48 Hours |
| Sealing | IP67 |
Quality & Compliance
| Qualified | Yes – Commercial Version |
|---|---|
| Specification | 8D Series |
| Series | 8D Series III |
| VAD | 48 Hours |
