8D023K54SN
Eaton Souriau 8D023K54SN 8D Series III Square Flange Receptacle, Shell Size 23 with Stainless Steel Passivated Plating, 4#12,9#16,40#22D Female Sockets Contacts, N Orientation. Ideal for Aerospace, Armoured Vehicles, Energy, Helicopter, Industrial, Maritime, Military, Naval, Railway.
Technical Specifications
| Manufacturer | Eaton Souriau |
|---|---|
| Connector Style | Square Flange Receptacle |
| Contact Gender | Socket – Female |
| Contact Size | 4#12, 40#22D, 9#16 |
| Contacts Supplied | Yes |
| Insert Keyway | N |
| Insert Arrangement | 23-54 |
| No of Contacts | 53 |
| Shell Material | Stainless Steel |
| Shell Plating | Passivated (K) |
| Shell Size | 23, 23 (H) |
| Termination Method | Crimp |
| Mating Cycles | 500 |
| Shell Continuity | 10 mΩ |
| Shielding | 45 db at 10 GHz |
Environmental Specifications
| Operating Temperature | -65°C +200°C – -85°F +392°F |
|---|---|
| RoHS Compliant | Yes |
| Salt Spray | 500 Hours |
| Sealing | IP67 |
Quality & Compliance
| Qualified | Yes – Commercial Version |
|---|---|
| Specification | 8D Series |
| Series | 8D Series III |
| VAD | 72 Hours |
