8LT519F35PN
The Eaton Souriau 8LT519F35PN is an 8LT Series I commercial circular connector. Featuring a Size 19 Aluminium Alloy shell with Nickel plating, and 66#22D Male Pins in N orientation. Ideal for Aerospace, Military, Industrial, Energy, Maritime and Naval applications. This connector is engineered for robust performance in industrial and commercial systems.
Technical Specifications
| Manufacturer | Eaton Souriau |
|---|---|
| Connector Style | Plug with RFI Shielding |
| Contact Gender | Pin - Male |
| Contact Size | 66#22D |
| Contacts Supplied | Yes |
| Insert Keyway | N |
| Insert Arrangement | 19-35 |
| No of Contacts | 66 |
| Shell Material | Aluminium Alloy |
| Shell Plating | Nickel |
| Shell Size | 19 |
| Termination Method | Crimp |
| Mating Cycles | 500 |
| Shell Continuity | 1 mΩ |
| Shielding | 90 db at 100 MHz |
Environmental Specifications
| RoHS Compliant | Yes |
|---|---|
| Salt Spray | 500 Hours |
| Sealing | IP67 |
Quality & Compliance
| Qualified | Yes - Commercial Version |
|---|---|
| Specification | 8LT Series |
| Series | 8LT Series |
| VAD | 48 Hours |
