MS3102E24-5S*
MS3102E24-5S/ YH3102E24-5S MIL-DTL-5015 Style Box Mount Receptacle, Green Zinc, Shell Size 24, 16#16 Socket Contacts.
Technical Specifications
| Manufacturer | Yeonhab |
|---|---|
| Connector Style | Box Mounting Receptacle |
| Contacts Supplied | Yes |
| Contact Gender | Socket - Female |
| Contact Size | 16#16 |
| No of Contacts | 16 |
| Termination Method | Solder |
| Coupling Style | Threaded |
| Insert Arrangement | 24-5 |
| Insert Keyway | Normal |
| Shell Size | 24 |
| Shell Material | Aluminium Alloy |
| Shell Plating | Green Zinc |
| Mating Cycles | 500 |
Environmental Specifications
| Operating Temperature | -55°C to +125°C / -67°F to +257°F |
|---|
