Yeonhab

MS3102E24-5S*F2

MS3102E24-5SF2 / YH3102E24-5S-02 MIL-DTL-5015 Style Box Mount Receptacle, Electroless Nickel, Shell Size 24, 16#16 Socket Contacts.

Ordering Information

48 in stock (can be backordered)

Estimated Factory Lead Time: Please contact the office for more information.

Require more? Enquire Here

Technical Specifications

ManufacturerYeonhab
Connector StyleBox Mounting Receptacle
Contacts SuppliedYes
Contact GenderSocket - Female
Contact Size16#16
No of Contacts16
Termination MethodSolder
Coupling StyleThreaded
Insert Arrangement24-5
Insert KeywayNormal
Shell Size24
Shell MaterialAluminium Alloy
Shell PlatingNickel
Mating Cycles500

Environmental Specifications

Operating Temperature-55°C to +125°C / -67°F to +257°F
